Ergonomic Bag Handle For Stitching Onto Fabric Bag
Buyer Information
I need bag handles with to be stitched later. I have provided following requirements slight variations can be possible. Please email me details so that my team can research on it and then respond:
Support 20 kg working load
Be suitable for stitching to heavy fabric (polyester, canvas, nylon)
Withstand repeated lifting cycles
Be comfortable for hand carrying
DIMENSION SPECIFICATION
All dimensions in mm.
Feature Required Dimension
Total Length 150 mm
Grip Length (center section) 110 mm
Overall Width 35–40 mm
Overall Height 30–35 mm
Grip Thickness 28–32 mm
Wall Thickness Minimum 3 mm
Grip must be ergonomic oval shape.
STITCHING BASE REQUIREMENT
Each side of the handle must have a flat sewing flange.
End Flange Specification:
Feature Dimension
Flange Length 25–30 mm
Flange Width 35–40 mm
Flange Thickness 4–5 mm
Stitching Hole Diameter 4–6 mm
Number of stitch holes 2-4 per side
MATERIAL REQUIREMENT
Preferred:
PA6 GF30 (Glass reinforced nylon)
OR
PP high impact
OR
ABS heavy-duty grade
Mechanical Requirements:
Tensile strength ≥ 80 MPa
No cracking under 30 kg load
Heat resistance ≥ 50°C
SURFACE FINISH
Matte texture
No sharp edges
Smooth ergonomic contour
No flashing
No sink marks
PRODUCTION DETAILS REQUEST
Unit cost at 1,000 / 5,000 / 10,000 pieces
Mold cost
Mold lifetime
Sample lead time
Mass production lead time
the generated image is in attachment
